| Item No: | Descriptions | Unit | Your Product Measurements: | ||
| 1 | Material of the Woven Fabric DIN60001 | Polyester | |||
| 2 | Weave DIN ISO 9354 | Plain Weave | |||
| 3 | Count of Yarn | Warp: | Denier | 1000 | |
| Weft: | Denier | 1000 | |||
| 4 | Setting/ Number of Threads | Warp: | Threads/cm | 12 | |
| DIN EN 1049 | Weft: | Threads/cm | 12 | ||
| 5 | Base Coat | PVC | |||
| 6 | Weight of the cloth DIN EN 12127 | g/m² | 120 | ||
| 7 | Total Weight DIN EN ISO-2286-2 | g/m² | 700 | ||
| 8 | Tensile Strength DIN 53354 | Warp: | N/5cm | 1800 | |
| Weft: | N/5cm | 1600 | |||
| 9 | Tear Resistance DIN 53363 | Warp: | N | 250 | |
| Weft: | N | 220 | |||
| 10 | Adhesion (Coating) DIN 53357 | N/5cm | 100 | ||
| 11 | Adhesion (Welding) | Kg/5cm | 10 | ||
For the ventilation duct, we can make it to be anti static at 10*8.
Our tarpaulin for airduct is fire resistant, it is M1 and B1 and NFPA701 compliant.
We use high strength polyester fabric to make the tarpaulin, the tear strength can reach to 400N.
Normally, we pack 50M per roll with craft paper. But for the tarpaulin used to make flexible duct, some customers need 500M or 1000M length per roll, we can pack as customers requirement.
