| Item No: | Descriptions | Unit | Your Product Measurements: | |
| 1 | Material of the Woven Fabric DIN60001 | Polyester | ||
| 2 | Weave DIN ISO 9354 | Panama | ||
| 3 | Count of Yarn | Warp: | Denier | 1500 |
| Weft: | Denier | 1500 | ||
| 4 | Setting/ Number of Threads | Warp: | Threads/cm | 32 |
| DIN EN 1049 | Weft: | Threads/cm | 32 | |
| 5 | Base Coat | PVC | ||
| 6 | Weight of the cloth DIN EN 12127 | g/m² | 410 | |
| 7 | Total Weight DIN EN ISO-2286-2 | g/m² | 1100 | |
| 8 | Tensile Strength DIN 53354 | Warp: | N/5cm | 6000 |
| Weft: | N/5cm | 5500 | ||
| 9 | Tear Resistance DIN 53363 | Warp: | N | 600 |
| Weft: | N | 550 | ||
| 10 | Adhesion (Coating) DIN 53357 | N/5cm | 150 | |
| 11 | Adhesion (Welding) | Kg/5cm | 15 |
The doubel sides PVC make the coated fabric has excellent waterproof performance.
We use high strength polyester fabric to coate, the coated fabric has high tear and tensile strength.
The PVC coated fabric is easy to welding by high frequency welding machine or hot air welding machine, it can be also glued with PVC glue.
Yes, our PVC coated polyester fabric is fire retardant, it will extinguish immediately after leaving the fire.
